ESIT CAD DIGITAL LOAD CELL

Digital technology in load cell



  • RS485 communication
  • Automatic corner calibration
  • Measurement error detection
  • 24 bit A/D converter
  • IP68 industrial protection
  • Lightning Protection
  • %100 resistant to side forces
  • %300 resistant to over load
  • Installation angle compensation
  • Welded hermetic sealed body
  • Measurement error detection

10/20/30 TONNE
LEVEL ADJUSTMENT WITH LED
ELECTRONIC ANGLE COMPANSATION

ESIT ECI AUTOMATIC

Easy weighing automation






  • Graphics Display (4.5”) and capacitive touch buttons
  • Adaptive, indexed menu system
  • Internet-based recipe entry software
  • Easy connection with connectors (Solder-free)
  • 1600 Hz measurement / 800 Hz data output rate
  • USB reporting / update / backup / calibration backup
  • Indexed menu system and multi language option
  • Esit gResolver superior multi-frequency vibration filtering technology
  • Easy digital calibration (mV, factory, coefficient)
  • IP65 protection class front panel
  • Intelligent plug and play type option cards and modular expansion
  • Service menu (self-diagnostic)
  • Printer support
  • Besides load cell connection in standard configuration USB serialcommunication and external display output
  • Akıllı tak çalıştır opsiyon kartları ve modüler genişleme
  • Esit gResolver superior multi-frequency vibration filtering technology
  • Intelligent plug and play type option cards and modular expansion
BAGGING SCALE FUNCTION
HOPPER SCALE FUNCTION
RECIPE FUNCTION

ESİT ECI DYNAMIC

Rapidity ​​and accuracy in dynamic weighing






  • Graphics Display (4.5”) and capacitive touch buttons
  • Adaptive, indexed menu system
  • Internet-based recipe entry software
  • Easy connection with connectors (Solder-free)
  • 1600 Hz measurement / 800 Hz data output rate
  • USB reporting / update / backup / calibration backup
  • Indexed menu system and multi language option
  • Esit gResolver superior multi-frequency vibration filtering technology
  • Easy digital calibration (mV, factory, coefficient)
  • IP65 protection class front panel
  • Intelligent plug and play type option cards and modular expansion
  • Service menu (self-diagnostic)
  • Printer support
  • Besides load cell connection in standard configuration USB serialcommunication and external display output
  • Akıllı tak çalıştır opsiyon kartları ve modüler genişleme
  • Esit gResolver superior multi-frequency vibration filtering technology
  • Intelligent plug and play type option cards and modular expansion
WEIGH FEEDER SCALE FUNCTION
FLOW SCALE FUNCTION
CHECKWEIGHER FONKSİYONU

ESIT SMART-2

Intelligent indicator for all conditions


Small indicator with 1/10000 accuracy. Designed to be used both for overload control in cranes and elevators, and high accuracy weighing such as tank weighing. It is also a low cost solution to many applications thanks to it's built in 2 relay and connectivity options such as RS485 output, wi-fi and bluetooth.


  • Optional Wi-fi and Bluetooth connections
  • Analog output (0-5 V)
  • Internal 2 relay outputs
  • Dust and humidity-proof membrane keyboard
  • RS232/RS485 serial output
  • Taring, zeroing, function keys
  • Zeroing within the entire measurement range
  • Gain adjustment for load cell output
  • 5-digit LED weight display
  • Android smart phone application

Get rid of cables with Wifi
One-to-one and quick contact with Bluetooth
Easy control with built-in role
Outdoor compatible IP67
